High Temperature RO Membrane | HSRO

1. Specially formulated membrane sheet to resist thermal ageing, suitable for frequent high-temperature CIP cycles
2. Dual feed spacer options (34mil / 46mil) to optimize flow distribution and reduce channel blockage
3. Maintains reliable desalination performance when running at the upper temperature limit
4. Flexible pH working window, compatible with commonly used acidic and alkaline cleaning agents
5. Standard spiral structure, directly interchangeable with matched pressure vessel housings

Send Inquiry

High Temperature RO Membrane | HSRO

RO Membrane Performance Parameters

model	HSRO-8040/34SU	HSRO-8040/46SU
Feed Spacer (mil)	34	46
Membrane Area(ft²/m²)	365(34)±3%	290(27)±3%
Operating Temp. (℃)	15-70
Cleaning Temp. (℃)	90
Initial Salt Rejection (%)	98.5%(NaCl)

Product size parameter

Membrane element size	A (±2.0mm)	B(±0.5mm)	C (±0.1mm)
1812	305	15.7	45
8038	965	28.8	200

Application Scenarios

Hot-condition pure water manufacturing for industrial production lines
Steam condensate recovery & water-energy reuse to cut operation cost
Concentration of edible sugar series solutions in food manufacturing
Concentration treatment for temperature-sensitive chemical feed liquid
Pharmaceutical workshop process water and equipment wash water preparation

Related Knowledge

Types of Membrane Fouling

Adsorption Fouling

Organics adsorb onto the membrane surface. Contaminants build up within membrane pores, shrinking pore size and raising membrane resistance. This fouling is difficult to remove. Main contaminants are dissolved substances and emulsions.

Scaling Fouling

Salts in raw water exceed solubility and precipitate as scale on membranes. Contaminants include colloids and particles: organics like fats, proteins and humic acid; inorganics such as calcium, magnesium, iron and phosphorus salts.

Biofouling

Microbes accumulate at the membrane-water interface in two phases: adhesion and growth. If biocide dosage is insufficient, attached microbes feed on nutrients and multiply to form biofilms, mainly bacteria and algae.

Warranty Period

The company warrants the performance of membrane elements for three 3 years. The three-year warranty period shall commence on the earliest of the following dates:

The date when the reverse osmosis system is put into operation;
Six 6 months from the date the membrane elements are shipped from the manufacturing site;
Three 3 months after the membrane elements are shipped from Guangzhou / Shanghai, China to Taiwan of China, Japan, South Korea, Thailand, India, Malaysia, the United States and other designated locations in China.
