Acid-Resistant High-Pressure Reverse Osmosis Membrane Elements
Brand Name: NANOIMP
OEM/ODM: Accept
Manufacturer: Yes
Delivery Time: 3-15 days
Shipping Support: Express / Sea/ Land
Place of Origin: Hangzhou, China
E-mail: lena.hu@nano-sepmer.com
Main Models: ASRO-8040/34FO | ASRO-8040/46FO
Product Performance Parameters
|
model |
ASRO-8040/34FO |
ASRO-8040/46FO |
|
Membrane area (ft2/m2) |
365(34)±3% |
300(27)±3% |
|
ratio of desalinization (%) |
99.5% |
|
|
Permeate flow (GPD/m3d) |
5600/21 |
4500/17 |
|
Acid concentration tolerance |
Phosphorus: ≤15% hydrochloric/sulfuric acid: ≤10% |
|
|
Maximum operating temperature (°C) |
≤40 |
|
|
Maximum operating pressure (psi/bar) |
≤1305(90) |
|
|
Normal operation pH |
1-7 |
|
|
Customizable size |
2540/4040/8040 |
|
Product Size Parameters
(1) Flat Head
|
Membrane element size |
A (±2.0mm) |
B (±0.1mm) |
C (±0.5mm) |
|
8040 |
1016 |
28.8 |
200 |
(2) Protruding End
|
Membrane element size |
A (±2.0mm) |
B (±0.1mm) |
C (±0.5mm) |
D (±0.1mm) |
|
2540 |
1016 |
30.2 |
19.1 |
61 |
|
4040 |
1016 |
26.7 |
19.1 |
100 |
Application Scenarios
- Metal pickling waste liquid treatment: Concentrate pickling wastewater and acidic mother liquor from steel and hardware industries, recover acid and heavy metal resources.
- Chemical acidic mother liquor recovery: Concentrate and purify acidic feed liquid in chemical industry, reduce waste discharge and realize material recycling.
- Acid mine wastewater treatment: Intercept heavy metal ions and salts in heavy metal-containing acid mine wastewater, reduce waste volume to meet discharge standards.
- Special acidic process water reuse: Concentrate wastewater from phosphoric acid and sulfuric acid systems, adapt to high-acid working conditions for water recycling.
- New energy battery materials: Recover phosphoric acid from iron phosphate / lithium iron phosphate production, recover sulfuric acid in wet dismantling of power batteries.
Related Knowledge
Membrane Storage
Membrane elements are made of organic materials. Bacterial growth on the membrane surface can damage the active layer and result in loss of membrane performance. Therefore, if the membrane system will be shut down for a period of time, different preservation solutions shall be prepared and kept inside the system according to the downtime duration to prevent bacterial proliferation.
WARNING! Once the membrane module is wetted by water, it must be kept wet at all times. Drying out is strictly prohibited, otherwise the membrane sheet will be damaged and the membrane warranty terms will become invalid.
| Maximum Storage Duration | Preservation Solution |
| 3 days | Fill the system with deionized water. Add 18% V/V glycerol mixture if ambient temperature is below 0℃. |
| 7 days | 0.1% V/V Proxel Gxl solution. After thorough mixing, adjust pH to 4.5–5.0 with citric acid, and circulate for 30 minutes at 10–25℃. Add 18% V/V glycerol mixture if ambient temperature is below 0℃. |
| 30 days | 0.2% V/V Proxel Gxl solution. After thorough mixing, adjust pH to 4.5–5.0 with citric acid, and circulate for 30 minutes at 10–25℃. Add 18% V/V glycerol mixture if ambient temperature is below 0℃. |
| 12 months | 0.25% V/V Proxel Gxl solution plus 18% V/V glycerol (98% reagent grade). After thorough mixing, adjust pH to 4.5–5.0 with citric acid, circulate for 60 minutes at 10–25℃. Renew the preservation solution every three months. Add 18% V/V glycerol mixture if ambient temperature is below 0℃. |
Warranty Period
The company warrants the performance of membrane elements for three 3 years. The three-year warranty period shall commence on the earliest of the following dates:
- The date when the reverse osmosis system is put into operation;
- Six 6 months from the date the membrane elements are shipped from the manufacturing site;
- Three 3 months after the membrane elements are shipped from Guangzhou / Shanghai, China to Taiwan of China, Japan, South Korea, Thailand, India, Malaysia, the United States and other designated locations in China.
